Product Details
- High flow performance supports demanding commercial applications
- High capacity per tank delivers up to 1,200,000 grains for extended operation
- Flexible system configurations support single through multi-unit designs
- Advanced controls provide system visibility
- Fully adjustable regeneration cycles provide flexible operation
- High-capacity resin delivers consistent commercial-grade softening performance
- Durable fiberglass-reinforced mineral tanks resist corrosion for long-term reliability
- Top-mounted valve design allows easier access for servicing and maintenance
- NSF-certified components ensure trusted material quality and system integrity
Options
- Progressive flow operation
- Separate source regeneration capability
- ASME-rated tanks (18” and up)
- Multi-unit system controller
- Multiple valve sizes
Specifications
Continuous Service Flow Rate (GPM) @15 psi pressure loss
up to 207 gpm
Rated Capacity (Grains @ 15 lb. salt)
up to 1,200,000
Min Pressure (psi)
30 psi
Max Pressure (psi)
100 psi
Min Temperature
40 F
Max Temperature
100 F
Pipe Size
1"-3"
Resin Volume (cu.ft.)
up to 40.0 cu.ft.
Certification
NSF Certified Components
